Round Belt Joint Kits

Bayrich round belt joint machine is professional round belt joint machine. After heating the PU belt ,it will melt on to ends, and then connect the two ends quickly, and after the temperature cools down, take out the round belt to grinding the overflowing material, so that an endless round belt is completed.
Polyurethane round belt has been widely used to replace glass fiber insulation materials, wood, traditional rubber products, etc.
The round belt is generally divided into smooth round belt and rough round belt: the round light belt is orange, and the round rough belt is dark green.
The specifications can be produced from ∮ 2 to ∮ 30; The light band has good surface finish, bright color, rough rough surface, uniform and tidy particles, comfortable feel and wide application range.
Product features: extremely high tension resistance, tensile strength, wear resistance, impact resistance, oil resistance, water resistance, chemical resistance, no plasticizer, wide range of use temperature, not easy to extend, easy to weld, easy to install, and long service life.
Operation mode: transportation of packaging machine, printing machine, textile machine, transmission wheel, ceramic tile, cement brick, floor tile, food, wooden products, cans, newspapers, printing materials, etc.

Beschrijving
Feature



1. Using professional equipment processing can make the joint of the round belt more firm and not easy to crack.the joint is firm and not easy to break.

2. Temperature: adjustable from 0-300°C.

3. The scissors have a scale on them, making the cut more smooth.



Technical Datasheet



How to use Bayrich round belt joint kits

product-399-617

1. Use round belt scissors to trim both ends of the belt. If the end is not flat then the hot melt on the surface of the round belt is not sufficient, the interface will be easy to break.



2. Fix the round belt on the connector.

product-399-617

product-399-617

3. Adjust the hot melter to 250°c and fix both ends of the belt on the connector.



4. Lock the connector and wait 2-3 miniutes to wait the belt cool down.



5. Take out the belt and grinding the connected parts to smooth.







product-399-617



Automatic round belt Joint machine and grinding machine

product-460-460

product-460-460

1. For diameters 3-13mm round belt

2. Need extra air supply

3. Can make extra clamp for 6-17mm top width V-belt, clamp cost is extra 100usd/pc

For grinding diameters 3-13mm round belt after joint
